UpKeep Edge

The sensor platform for maintenance teams

Leverage UpKeep’s sensor solution to track temperature, humidity, current draw, vibration, runtime, and more. Detect conditions outside the normal range and trigger notifications and work orders. Build a preventive maintenance program based on runtime hours. Track asset downtime and availability.

Wireless Sensors
Sensors collect temperature, humidity, current draw, vibration, and runtime data from your assets.

IoT Gateway
An IoT gateway centralizes the sensor data and sends it to UpKeep’s servers. All gateways come with out of the box cellular and Ethernet connectivity.

Web Platform
UpKeep processes the data and makes it available to detect issues, simplify preventive maintenance, and track downtime and availability.

Join 4,000+ companies already growing

Sensor List

Description

Data Properties

Use Cases

Temperature Sensor

-40°F to 257°F measurement range (with lead)
-4°F to 130°F operating range
ISO-17025 (NIST) Certified (25 months)
10 minute reading intervals Available with or without a lead

Temperature

Monitor temperature conditions

Humidity Sensor

0 to 100% humidity measurement range
-13°F to 158°F temperature measurement range (with lead)
-4°F to 130°F operating range ISO-17025 (NIST) Certified (7 months)
Available with or without a lead

Humidity
Temperature
Dew point
Moisture weight
Heat index

Monitor temperature and humidity conditions

AC Current 150 Amp Sensor

Single phase AC current
0 to 150 amp measurement range
-18°C to 55°C (0°F to 130°F) operating range
10 minute reading intervals

Average current
Minimum current
Maximum current
Amp hours

Monitor average, minimum, and maximum current conditions
Track runtime hours
Track downtime and availability

Vibration Sensor

10 foot lead
Tri-axis vibration and temperature
4200 Hz / 252,000 RPM vibration measurement range
-40°F to 221ºF temperature measurement range
-13°F to 185°F operating range
IP-65 NEMA rated industrial enclosure
10 minute reading intervals

Frequency
Acceleration Peak
Acceleration RMS
Velocity RMS
Displacement Peak to Peak
Crest Factor
Duty Cycle
Temperature

Monitor vibration and temperature conditions

Temperature Sensor

Description

-40°F to 257°F measurement range (with lead)
-4°F to 130°F operating range
ISO-17025 (NIST) Certified (25 months)
10 minute reading intervals Available with or without a lead

Data Properties

Temperature

Use Cases

Monitor temperature conditions

Humidity Sensor

Description

0 to 100% humidity measurement range
-13°F to 158°F temperature measurement range (with lead)
-4°F to 130°F operating range ISO-17025 (NIST) Certified (7 months)
Available with or without a lead

Data Properties

Humidity
Temperature
Dew point
Moisture weight
Heat index

Use Cases

Monitor temperature and humidity conditions

AC Current 150 Amp Sensor

Description

Single phase AC current
0 to 150 amp measurement range
-18°C to 55°C (0°F to 130°F) operating range
10 minute reading intervals

Data Properties

Average current
Minimum current
Maximum current
Amp hours

Use Cases

Monitor average, minimum, and maximum current conditions
Track runtime hours
Track downtime and availability

Vibration Sensor

Description

10 foot lead
Tri-axis vibration and temperature
4200 Hz / 252,000 RPM vibration measurement range
-40°F to 221ºF temperature measurement range
-13°F to 185°F operating range
IP-65 NEMA rated industrial enclosure
10 minute reading intervals

Data Properties

Frequency
Acceleration Peak
Acceleration RMS
Velocity RMS
Displacement Peak to Peak
Crest Factor
Duty Cycle
Temperature

Use Cases

Monitor vibration and temperature conditions
